Integrated Wide-Bandwidth Current Sensing

The book provides a single-source reference for current sensing integrated circuit design, focusing on wide-bandwidth current sensing for applications in industrial electronics, renewable energies, smart grids, electromobility, and the Internet of Things. It covers modeling and optimization of on-chip Rogowski coil and Hall sensor, noise reduction techniques, open-loop and closed-loop sensor front-end design, and the first on-chip and off-chip current sensors with planar and helix-shaped coils.

Format: Paperback / softback
Length: 135 pages
Publication date: 06 September 2021
Publisher: Springer Nature Switzerland AG

This book offers a comprehensive and practical guide to current sensing integrated circuit design, catering to a wide range of applications in the fields of sensing, control, and optimization of energy flow. Written in a handbook style, it provides systematic guidelines and implementation examples, making it an invaluable resource for professionals and researchers in the field. The authors focus on the implementation of wide-bandwidth current sensing on a single microchip, which is essential for applications such as industrial electronics, renewable energies, smart grids, electromobility, and the Internet of Things. The book covers various aspects of current sensing, including modeling and optimization of on-chip Rogowski coil and Hall sensor in both lateral and vertical orientation, noise reduction techniques, open-loop and closed-loop sensor front-end design, and the first on-chip current sensor with a planar coil placed besides a power line to measure internal signal currents and the first off-chip current sensor with a helix-shaped coil for external signal currents in the multi-MHz region. With its comprehensive coverage and practical approach, this book is an essential tool for anyone involved in the design and development of current sensing integrated circuits.

Weight: 244g
Dimension: 235 x 155 (mm)
ISBN-13: 9783030532529
Edition number: 1st ed. 2020
