The Art of Timing Closure: Advanced ASIC Design Implementation

The Art of Timing Closure is a book that provides a hands-on approach to advanced concepts and techniques in ASIC design implementation using Multi-Mode Multi-Corner (MMMC). It covers physical design, Static Timing Analysis (STA), formal and physical verification, and is intended for practicing ASIC design implementation engineers and students.

Format: Paperback / softback
Length: 204 pages
Publication date: 05 August 2021
Publisher: Springer Nature Switzerland AG

The Art of Timing Closure is a comprehensive guide that employs a hands-on approach to elucidate advanced concepts and techniques related to advanced ASIC design implementation. It specifically focuses on the physical design, Static Timing Analysis (STA), formal and physical verification. The scripts in this book are based on Cadence® Encounter System™, a widely used EDA tool. However, it is worth noting that the commands demonstrated in this book are generally similar to those in other EDA tools.

The book is organized into several chapters, each covering a distinct aspect of physical design and timing analysis. The topics covered include:

Data Structures: This chapter introduces the fundamental data structures used in physical design and timing analysis, such as queues, stacks, and trees. It also discusses the importance of data structure selection and optimization for efficient circuit implementation.

Multi-Mode Multi-Corner Analysis: This chapter delves into the analysis of multi-mode circuits, which are characterized by different operating modes and different corners (performance metrics). It covers techniques such as multi-mode timing analysis, multi-corner optimization, and mixed-signal simulation.

Design Constraints: This chapter discusses the various design constraints that must be considered during the physical design process, such as power consumption, area, timing, and electromagnetism. It provides guidelines for designing circuits that meet these constraints while achieving optimal performance.

Floorplan and Timing: This chapter focuses on the floorplan design and timing analysis of integrated circuits. It covers topics such as placement and routing, clock tree synthesis, and final route and timing verification.

Placement and Timing: This chapter explores the placement and timing optimization of components within the circuit. It covers techniques such as pin assignment, clock skew balancing, and timing closure.

Clock Tree Synthesis: This chapter discusses the clock tree synthesis process, which involves designing a clock network that meets the timing requirements of the circuit. It covers topics such as clock tree synthesis algorithms, clock tree power analysis, and clock tree optimization.

Final Route and Timing: This chapter focuses on the final route and timing verification of the circuit. It covers techniques such as timing analysis, clock latency analysis, and timing closure.

Design Signoff: This chapter discusses the design signoff process, which involves verifying the correctness verification of the circuit. It covers topics such as design rule checking, design for testability, and design for manufacturability.

Throughout the book, the author emphasizes short, clear descriptions that are supported by authoritative manuscripts. The primary goal of this book is to provide a comprehensive understanding of physical design and timing analysis at each stage of the physical design process. It aims to showcase the interdependence of physical design and timing analysis engineering and present them as a unified area of expertise.

The Art of Timing Closure is intended for a wide range of audiences, including practicing ASIC design implementation engineers and students pursuing advanced courses in ASIC design. It provides a solid foundation for anyone interested in advancing their knowledge and skills in this field. The book's practical approach and comprehensive coverage make it an invaluable resource for anyone involved in ASIC design implementation.

Weight: 349g
Dimension: 235 x 155 (mm)
ISBN-13: 9783030496388
Edition number: 1st ed. 2020
